In the intelligent automotive industry, high-performance MCUs have become the core of innovation. Infineon’s AURIX™ TC4x series represents the latest technological advancement in automotive-grade MCUs, providing powerful support for next-generation automotive electronic systems. This article explores the technical features, application scenarios, and role of the TC4x series in the evolution of automotive electronics.
AURIX TC4x: Technical Overview
TC4x is Infineon’s fourth-generation AURIX microcontroller, enhancing performance, safety, and integration over its predecessors, specifically designed to meet modern vehicles’ high computing power, safety, and real-time processing requirements.
Core Architecture and Processing Capability
TC4x employs an advanced multi-core architecture, integrating up to six TriCore™ CPU cores, with frequencies reaching 300MHz, using the TriCore 1.8 architecture. The series introduces SIMD units and DSP functionality, efficiently handling parallel computing tasks.
The highest configuration can deliver over 4,500 DMIPS processing power, suitable for ADAS, domain controllers, and powertrain control applications.
Memory and Storage Technology
TC4x achieves breakthroughs in memory architecture, providing up to 64MB on-chip flash and 6MB SRAM, using MLC technology to increase storage density and optimize power consumption. The large storage capacity supports complex software architectures and future functional expansions.
TC4x introduces advanced MPU and region protection mechanisms to ensure the security of critical data and code.
Security Architecture and Functional Safety
Safety is a primary consideration in TC4x design. It complies with ISO 26262 ASIL-D standards and provides comprehensive functional safety features:
- Hardware Security Module: Independent security processor responsible for key management and encryption operations
- Lockstep Core Design: Critical CPUs employ redundant design for real-time error detection
- Memory Error Detection and Correction: Protects data from interference
- Safety Monitoring: Includes watchdog timers, voltage and clock monitoring
- Multi-layer Security Concept: Comprehensive solution from hardware to software
These features enable TC4x to meet the most stringent automotive safety standards, suitable for scenarios with high safety requirements.
Network Connectivity and Communication Interfaces
In modern connected vehicles, network communication capability is crucial. AURIX TC4x integrates rich communication interfaces:
- Up to 10 Gigabit Ethernet interfaces, supporting TSN (Time-Sensitive Networking) and IEEE 1588 standards
- Up to 24 CAN-FD channels, compatible with the latest CAN XL standard
- Multiple LIN, SPI, I²C, and FlexRay interfaces
- PCIe interface for convenient connection with high-performance processors and external devices
These rich communication options make TC4x an ideal choice for domain controllers and gateway applications, efficiently handling in-vehicle network communications.
Key Application Areas for AURIX TC4x
The AURIX TC4x series, with its powerful performance and rich functionality, has broad application prospects in multiple automotive electronic domains.
Advanced Driver Assistance Systems (ADAS)
With the development of autonomous driving technology, ADAS systems demand higher computing capabilities from microcontrollers. AURIX TC4x provides an ideal platform for ADAS applications:
- High-performance multi-core architecture capable of processing complex sensor fusion algorithms
- Dedicated radar signal processing accelerators, improving millimeter-wave radar system efficiency
- Real-time processing capability ensures timely response to dangerous situations
- ASIL-D level safety features guarantee the reliability of critical driving functions
In specific applications, TC4x can be used for adaptive cruise control, automatic emergency braking, lane keeping assistance, and other ADAS functions, laying the foundation for achieving higher levels of autonomous driving.
Domain Controllers and Central Computing Platforms
Automotive electronic architecture is evolving from distributed ECUs to centralized domain controllers. AURIX TC4x, with its powerful computing capabilities and communication functions, is highly suitable as the core of domain controllers:
- Powertrain Domain Controller: Managing engine, transmission, and powertrain systems
- Chassis Domain Controller: Integrating steering, suspension, and braking system controls
- Body Domain Controller: Managing lighting, air conditioning, seats, and other comfort systems
- Gateway Controller: Enabling data conversion and routing between different network protocols
TC4x’s multi-core architecture and virtualization support allow it to simultaneously run multiple safety-critical and non-safety applications, simplifying system design and reducing hardware costs.
Electric Vehicle Powertrain Control
In the electric vehicle field, AURIX TC4x provides high-performance solutions for motor control and battery management systems:
- High-precision PWM modules and ADC converters for accurate motor control
- Dedicated motor control interfaces, simplifying system design
- Powerful real-time processing capability, supporting advanced vector control algorithms
- Built-in safety features ensuring reliable powertrain operation
These characteristics make TC4x an ideal controller for electric vehicle inverters, DC-DC converters, and battery management systems, helping to improve electric vehicle efficiency and performance.
Functionally Safety-Critical Systems
For critical safety systems such as braking and steering, AURIX TC4x provides comprehensive functional safety support:
- Lockstep execution mode guarantees instruction execution correctness
- Multiple redundancy design enhances system reliability
- Advanced diagnostic functions for early fault detection
- Safety design compliant with ISO 26262 ASIL-D level
These features make TC4x particularly suitable for applications with extremely high safety requirements, such as electronic braking systems, electric power steering, and autonomous driving systems.
AURIX TC4x Alignment with Industry Trends
The design philosophy of AURIX TC4x highly aligns with the main development trends in the automotive electronics industry, demonstrating Infineon’s forward-thinking approach to future technology roadmaps.
Software-Defined Vehicles
As vehicle functions increasingly rely on software implementation, software-defined vehicles (SDV) have become the industry’s development direction. AURIX TC4x supports this trend:
- Powerful computing platform supporting complex software architectures
- Virtualization technology allowing multiple applications to run in secure isolation
- Support for OTA (Over-The-Air) updates, facilitating functional iterations
- Compatibility with automotive software standards like AUTOSAR, simplifying development
These features enable automakers to continuously provide new functions to users through software updates, extending the vehicle’s lifecycle value.
Automotive Cybersecurity
With enhanced vehicle connectivity, cybersecurity has become a key consideration. AURIX TC4x integrates comprehensive security functions:
- Hardware Security Module (HSM) supporting encryption algorithms and secure key management
- Secure boot and code authentication preventing unauthorized software execution
- Support for secure communication protocols such as TLS/DTLS
- Real-time intrusion detection capability
These functions enable TC4x to effectively defend against remote attacks and protect vehicle and user data security.
Real-time AI Processing
Artificial intelligence applications in the automotive field are increasingly widespread. TC4x has been optimized for edge AI processing:
- SIMD units and parallel processing capabilities accelerate AI algorithm execution
- Support for PPU (Parallel Processing Unit), improving neural network inference performance
- Efficient interfaces with GPUs and dedicated AI accelerators
These features enable TC4x to handle applications requiring AI technology, such as driver monitoring and environmental perception.
Development Ecosystem and Toolchain
Strong development support is a key factor for MCU success. Infineon provides a comprehensive development toolset and ecosystem for AURIX TC4x:
Software Development Tools
- AURIX Development Studio: Integrated development environment providing editing, compiling, and debugging in a one-stop solution
- TriCore Compiler and Debugging Toolchain: Optimizing code generation and execution efficiency
- MCAL Driver Library: Simplifying low-level hardware access
- AUTOSAR Middleware: Supporting standard software architecture
Hardware Development Platforms
- AURIX TC4x Starter Kits: Low-cost evaluation and learning platforms
- Application Kits: Development boards optimized for specific applications
- Emulators and Tracing Tools: Simplifying complex software debugging
Partner Ecosystem
Infineon collaborates with numerous software and tool suppliers to build a rich ecosystem for AURIX TC4x:
- Commercial RTOS Providers: Such as ETAS, Vector, Elektrobit (EB), etc.
- Functional Safety Toolchains: Supporting ISO 26262 development processes
- Model-Driven Development Tools: Supporting automatic code generation from tools like Simulink
This ecosystem greatly shortens product development cycles and reduces development difficulty and costs.
AURIX TC4x Comparison with Competitors
In the high-performance automotive MCU market, AURIX TC4x faces competition from multiple manufacturers. Here is a brief comparison with major competitors:
Compared to NXP S32 Series
- Advantages: Higher processing performance, richer on-chip storage, more comprehensive security features
- Challenges: NXP has a larger market share in North America with an extensive ecosystem
Compared to Renesas RH850 Series
- Advantages: Stronger network connectivity capabilities, more advanced multi-core architecture
- Challenges: Renesas has a deep foundation among Japanese automakers
Compared to STMicroelectronics SPC5 Series
- Advantages: Significantly leading performance, better scalability
- Challenges: STMicroelectronics products are more competitively priced
Overall, AURIX TC4x leads in performance, safety, and integration, particularly suitable for high-end automotive applications, while competitors may have advantages in specific market segments or price ranges.
Real Application Cases
AURIX TC4x has been adopted by multiple automakers and Tier 1 suppliers. Here are several typical application cases:
A German Luxury Brand’s Central Computing Platform
This automaker uses AURIX TC4x as the safety controller for its new-generation central computing platform, responsible for monitoring system operation and handling safety-critical functions. TC4x’s high performance and functional safety features enable it to ensure reliable operation of the entire system.
An American Electric Vehicle Manufacturer’s Battery Management System
This electric vehicle manufacturer chose TC4x as the core controller for its battery management system, utilizing its high-precision analog interfaces and real-time processing capabilities to monitor battery status, optimize charging and discharging processes, and improve battery lifespan and safety.
A Tier 1 Supplier’s Domain Controller Solution
This supplier developed a scalable domain controller platform based on TC4x, configurable as body, chassis, or powertrain domain controllers. This solution has been adopted by multiple automakers, greatly simplifying vehicle electronic architecture.
Future Development and Challenges
Although AURIX TC4x represents the highest level of current automotive MCUs, Infineon still faces some challenges and development opportunities as technology evolves:
Technical Challenges
- Power Management: As integration increases, thermal management becomes more complex
- AI Acceleration: Need to further enhance machine learning processing capabilities
- Safety Standard Evolution: Adapting to continuously evolving functional safety and cybersecurity standards
Market Challenges
- Price Pressure: Automakers continuously seek cost reductions
- Intensifying Competition: Traditional and emerging semiconductor companies actively positioning themselves
- Chip Shortage Impact: Supply chain risk management becomes increasingly important
Future Development Directions
Infineon may further develop the AURIX series in the following directions:
- Stronger AI processing capabilities, adapting to autonomous driving requirements
- Higher integration, incorporating more functions into a single chip
- Lower power consumption design, supporting electric vehicle long-range operation
- Enhanced security features, addressing evolving threats
Conclusion: Industry Significance of AURIX TC4x
Infineon’s AURIX TC4x series represents the cutting edge of automotive MCUs, providing a powerful computing platform for modern connected vehicles, electric vehicles, and autonomous vehicles. Its outstanding performance, comprehensive safety features, and rich connectivity options make it an important driving force in the transformation of automotive electronic architecture.
As the automotive industry evolves toward software-defined, highly automated, and electrified directions, high-performance MCUs like AURIX TC4x will continue to play a core role, driving automotive technology innovation and enhancing driving safety, comfort, and environmental protection. For automotive electronics engineers and system designers, a deep understanding of AURIX TC4x capabilities and applications will help develop more advanced, safer, and smarter automotive systems.
Frequently Asked Questions
What are the main improvements of AURIX TC4x compared to the previous generation TC3x?TC4x compared to TC3
